Hyster J2.2–3.5XN Electric Forklifts

Hyster J2.2–3.5XN Electric Forklifts

Type:standard forklift

Make:hyster

Power:Electric

Max Capacity:3.5 tonne

Electric Forklifts: 2.2-3.5 Tonnes

Clean, quiet electric forklift with class leading manoeuvrability deliver high performance and low energy consumption in a wide range of tough applications.

The J2.2-3.5XN series is available in two configurations – Advance & Advance+. Both versions offer highly productive travel and lifting performance, together with excellent manoeuvrability and reliability for both indoor and outdoor operations.

  • New drive axle, with dual-drive AC motors and a Zero Turning Radius steer axle allows faster, tighter manoeuvring in working aisles
  • Oil immersed brakes and HSM (Hyster Stability Mechanism) give the operator supreme confidence in the handling operation and increases productivity
  • A new ergonomically designed operator compartment provides a comfortable and highly productive operating environment for the driver
  • The electrical system features a CANbus communication network with Hall Effect sensors and is managed by the Pacesetter VSM (Vehicle System Manager) that continuously monitors truck operation and protects key components
  • Customisable performance settings and efficient systems help extend shift life and reduce battery change requirements (side battery extraction is available as an option)
  • Easy unrestricted service access with on-board diagnostics and a standard 1000hr service interval
J2.2XN J2.5XN J3.0XN J3.5XN
Load Capacity (kg) 2,200 2,500 3,000 3,500
Load Centre (mm) 500 500 500 500
Lift Height (mm) 6,000 6,000 5,810 5,810
Battery Capacity (V / Ah) 80V / 560Ah 80V / 560Ah / 700Ah 80V / 700Ah 80V / 700Ah
