Type:standard forklift

Make:hyster

Power:Electric

Max Capacity:3.5 tonne

Electric Forklifts: 2.2-3.5 Tonnes

Clean, quiet electric forklift with class leading manoeuvrability deliver high performance and low energy consumption in a wide range of tough applications.

The J2.2-3.5XN series is available in two configurations – Advance & Advance+. Both versions offer highly productive travel and lifting performance, together with excellent manoeuvrability and reliability for both indoor and outdoor operations.

  • New drive axle, with dual-drive AC motors and a Zero Turning Radius steer axle allows faster, tighter manoeuvring in working aisles
  • Oil immersed brakes and HSM (Hyster Stability Mechanism) give the operator supreme confidence in the handling operation and increases productivity
  • A new ergonomically designed operator compartment provides a comfortable and highly productive operating environment for the driver
  • The electrical system features a CANbus communication network with Hall Effect sensors and is managed by the Pacesetter VSM (Vehicle System Manager) that continuously monitors truck operation and protects key components
  • Customisable performance settings and efficient systems help extend shift life and reduce battery change requirements (side battery extraction is available as an option)
  • Easy unrestricted service access with on-board diagnostics and a standard 1000hr service interval

Type:standard forklift

Make:hyster

Power:Electric

Max Capacity:3.5 tonne

J2.2XN J2.5XN J3.0XN J3.5XN
Load Capacity (kg) 2,200 2,500 3,000 3,500
Load Centre (mm) 500 500 500 500
Lift Height (mm) 6,000 6,000 5,810 5,810
Battery Capacity (V / Ah) 80V / 560Ah 80V / 560Ah / 700Ah 80V / 700Ah 80V / 700Ah
