Yale GDP/GLP20-35VX
Yale GDP/GLP20-35VX
Yale GDP/GLP20-35VX

Type:standard forklift

Make:yale

Power:Internal Combustion

Max Capacity:3.5 tonne

Designed for medium and intensive duties

The Yale Veracitor VX forklift series is a feature rich series of engine powered fork lift trucks that offer high levels of productivity, ergonomics and dependability that deliver low lifetime ownership and running costs.

The 20-35VX LPG or Diesel models have been engineered to provide users with a model choice dependent on application requirements. Available in three model configurations the Base model is designed to provide a lower cost of acquisition without sacrificing performance, the Value model is optimised for performance and the lowest cost of operation while the Productivity model delivers maximum performance in heavy duty cycle applications.

Yale load Sensing Hydraulics (LSH) increases productivity and lowers fuel consumption by up to 15% (VDI test cycle) while the ECO-eLo Fuel Efficiency Mode can further reduce fuel consumption by up to 20% without having any significant negative effect on overall truck productivity under application conditions.

A raised operator cabin version is available where an elevated operator seat position for visibility over high loads is required.

Medium to intensive duty work cycle businesses where the VX series excels are:

  • Logistics and distribution
  • Large warehousing applications
  • Manufacturing

Ergonomic Features

  • Isolated powertrain and full suspension seat result in best-in-class whole body vibration levels of 0.6m/s2
  • Operator compartment with clear unobstructed foot space, easy 3 point entry and low step height for easy on and off access
  • Infinitely adjustable steering column and ergonomically positioned operators seat with integrated armrest incorporating mini-levers for hydraulic control and other key functions for the most comfortable operating position
  • Auto-deceleration system (ADS) is standard on the Value model automatically decreasing the speed of the truck when the throttle pedal is released minimising brake usage and operator fatigue
  • Dash display transmits continuous feedback to the operator of the trucks status and is positioned for optimum visibility

Performance Features

  • Three transmission options available, Standard electronic – Base model, Techtronix 100 – Value model for precise application matched performance and Techtronix 200X – Productivity model for maximum performance in heavy duty work cycles
  • Smooth electronic inching, shift and neutral start with brake interlock
  • Continuous stability enhancement system (CSE) provides operating confidence from outstanding lateral stability when travelling over uneven ground surfaces and when cornering
  • Controlled roll back on ramps for confident operator control on gradients
  • Controlled power reversal for regulated directional change and tyre savings
  • Intellix vehicle system manager (VSM) maximises uptime by monitoring and protecting key functions of the truck

Type:standard forklift

Make:yale

Power:Internal Combustion

Max Capacity:3.5 tonne

GDPGLP20 35VX Diesel LPG Forklift Truck App3 op GDPGLP20 35VX Diesel LPG Forklift Truck Main op

 Request Brochure

Specifications

GDP20VX GDP25VX GDP30VX GDP35VX
Load Capacity (kg) 2,000 2,500 3,000 3,500
Load Centre (mm) 500 500 500 500
Max Lift Height (mm) 6,588 6,588 6,494 6,494
Engine Type Yanmar 2.6L / Yanmar 3.0L / Kubota 2.4L Yanmar 2.6L / Yanmar 3.0L / Kubota 2.4L Yanmar 2.6L / Yanmar 3.0L / Kubota 2.4L Yanmar 3.0L / Kubota 2.4L
Transmission Electronic Powershift / Techtronix 100, 1-Speed / Techtronix 200, 2-Speed Electronic Powershift / Techtronix 100, 1-Speed / Techtronix 200, 2-Speed Electronic Powershift / Techtronix 100, 1-Speed / Techtronix 200, 2-Speed Electronic Powershift / Techtronix 200, 2-Speed
