Type:long loads

Make:combilift

Power:Electric or Internal Combustion

Max Capacity:25 tonne

Max Height:9 metres

Multi-Directional – Long Load Forklifts

The C-Series Combilift is a Multi-directional forklift, ideally suited to handle long loads safely, with greater speed and precision. Product range is available in both LPG / Gas, Diesel and electric / battery powered engines. The models have a range of mast options with lift heights up to 9m and lift capacities up to 25,000kgs. The C-Series Combilift can work in guided aisles as narrow as 2.1 Metres.

Have a look at our Steel Frame Solutions Case Study

Space Saving

Using patented, leading edge technology, the Combilift is equipped with a unique 4-way steering system, allowing the machine to travel sideways with long loads. This system gives the user multi-directional capability, delivering possible space savings of up to 100%. Narrow aisles and doorways are never a problem for the Combilift thanks to the advanced steering system and high level of control the driver has over the vehicle.

Safer Product Handling

The Combilift is designed to handle long-loads safely. It is tested to CE machinery directive and complies with ANSI/AMSE, B56.1 requirements. When travelling with a load, the Combilift can carry the load at a low level using the integrated platform. This keeps the load at a low centre of gravity, which means there is greater stability compared to a conventional forklift travelling with the load lifted high.
The enclosed cabin gives the driver full 360 degree visibility at all times. This is important when lifting and transporting loads, and working in areas where there are lots of pedestrians.

Long Loads Handling

The Combilift eliminates the unnecessary multiple handling of goods by being able to manoeuvre easily through doorways narrower than the load it carries. The Combilift is narrow enough to fit through your existing doorways, so there is no need to install wider doorways. It can also move straight into the aisle, eliminating the need for trolleys or roller conveyors. Having one vehicle capable of performing multiple tasks saves on time and on costs.

  • Combilifts’ Flagship Product
  • Multi-Directional Capabilities
  • Available in LP Gas, Diesel & Electric
  • Lift Heights up to 9.5m
  • Suitable for Both Indoor & Outdoor Use
  • Extensive Range of Attachments

Type:long loads

Make:combilift

Power:Electric or Internal Combustion

Max Capacity:25 tonne

Max Height:9 metres

Specifications

C2500 C3000 C3000E C3500 C4000 C4000E C4000 Deutz C5000 C5000E C5000XL C6000 C6000 Deutz C8000 C8000ET C10000 C12000 C14000 C25000
Load Capacity (kg) 2,500 3,000 3,000 3,500 4,000 4,000 4,000 5,000 5,000 5,000 6,000 6,000 8,000 8,000 10,000 12,000 14,000 25,000
Load Centre (mm) 600 600 600 600 600 600 600 600 600 600 600 600 600 600 600 600 600 1,200
Lift Height (mm) 4,040 4,040 4,040 4,040 4,040 4,040 4,040 4,040 4,040 4,040 4,536 4,536 4,536 4,536 4,100 4,100 4,100 4,120
Engine Type Kubota V1505-T Diesel / 2.2 ltr Toyota 4Y Engine LPG Kubota V1505-T Diesel / 2.2 ltr Toyota 4Y Engine LPG Kubota V1505-T Diesel / 2.2 ltr Toyota 4Y Engine LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V2403 T Diesel / 3 ltr GM LPG Kubota V3800 – TE Diesel / 4.3ltr GM LPG Kubota V3800 – TE Diesel / 4.3ltr GM LPG Kubota V3800 – TE Diesel / 4.3ltr GM LPG Kubota V3800 – TE Diesel / 4.3ltr GM LPG Kubota V3800 -TE Diesel / 4.3 ltr GM LPG Kubota V3800 -TE Diesel / 4.3 ltr GM LPG John Deere 4045 diesel engine John Deere Diesel Engine 6068HF485
