Hyster R30XM Order Picker

Hyster R30XM Order Picker

Type:order pickers



Max Capacity:1 tonne

High Level Order Pickers

The R30XM High Level Order Picker Series is designed for indoor use and ideally suited for a wide variety of applications such as home improvement warehouses and general warehousing.

Hyster OrderPickers provide productivity enhancing advantages, durability, serviceability and power.

  • Widely space VISTA mast channels provide a line of vision that is second to none.
  • Our optional adjustable console allows vertical adjustment to suit each operator providing better ergonomics for less operator fatigue.
  • With ULTIMAII multi-function control and return to center power steering help to make your operators as productive as possible.
  • To increase your speed, efficiency and productivity, the R30XM2 and R30XMA2 OrderPickers are equipped with the HySense® control system. It replaces the ‘step-downs’ at pre-set intervals of old, with new smooth, gradual linear speed reduction that is barely noticeable to your operators. This enables a more refined braking action while traveling at extended heights, bolstering confidence and productivity. And productivity is the bottom-line for any business.
  • The CANbus electrical system simplifies wiring, enhances reliability and affords you single point diagnostic capabilities through the console display gauge. Best of all, you don’t need a laptop or handset.
  • Through the use of SEM and a MOSFET transistor traction controller, we’ve eliminated the forward / reverse contactors, increasing reliability and reducing service needs. The controller’s adjustable plugging feature helps to minimize drive tire flat spots, to further reduce your maintenance costs.
  • The Auto Deceleration System of these OrderPickers, converts the kinetic regen-power back into electrical energy and sinks it back to the battery, improving battery efficiency and lengthening motor brush life.

Request brochure (PDF)

R30XMS3 Standard R30XM3 Counterbalanced R30XMA3 Straddle R30XMF3 Furniture Mover
Load Capacity (kg) 1,360 1,360 1,360 680
Load Centre (mm) 609 609 609 1,219
Voltage (V) 24 36 36 36
